ASUS PRO WS WRX90E-SAGE SE sTR5-SP6 Motherboard

Spesifikasi

• ASUS PRO WS WRX90E-SAGE SE
  • AMD socket sTR5 supports up to 96-core CPUs: Ready for AMD Ryzen Threadripper PRO 7000 WX-Series Processors.
  • Ultrafast connectivity:Seven PCIe 5.0 x16 slots, dual 10 Gb LAN ports, four M.2 slots, two rear USB4 40Gbps Type-C and SlimSAS NVMe support.
  • CPU and memory overclocking: Support for up to 2TB ECC R-DIMM DDR5 memory modules (1DPC)
  • Robust power and thermal design: 32 power stages with two 8-pin power connectors for the CPU, massive VRM cooling, chipset and M.2 heatsinks with active fans, and M.2 thermal pad.
  • PCIe Q-release Slim: Remove the graphics card by directly pulling it up, instead of pressing a PCIe latch.
  • Server-grade IPMI remote management:Hardware and software-level with a dedicated LAN port link to AST2600 BMC controller, plus ASUS Control Center Express software for real-time monitoring and management.
  • Trusted stability: Validated for extensive compatibility with the latest technologies, an expansive QVL list, and tested for 24/7 operation.

  SPECIFICATION :

  Model
  Pro WS WRX90E-SAGE SE
  CPU
  AMD Socket sTR5 for Ryzen™  Threadripper™  PRO 7000 WX-Series*
  Chipset
  AMD WRX90 Chipset
  Memory
  8 x DIMM slots, DDR5, ECC Registered Memory*
  8 Channel Memory Architecture

  *Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/.
  Expansion Slots
  AMD Ryzen™ Threadripper™ PRO 7000 WX-Series Processors*
  6 x PCIe 5.0 x16 slots
  1 x PCIe 5.0 x16 slot (x8 mode)

  *Please check the PCIe bifurcation table on the support site (https://www.asus.com/support/FAQ/1037507/)
  **To ensure compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals.
  Storage
  Total supports 4 x M.2 slots, 2 x SlimSAS ports and 4 x SATA 6Gb/s ports*
  AMD Ryzen™ Threadripper™ PRO 7000 WX-Series Processors*
  M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
  M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)
  M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
  M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode)
  AMD WRX90 Chipset
  2 x SlimSAS slots support PCIe 4.0 x4 mode NVMe device
  4 x SATA 6Gb/s ports

  * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/5/10 and SATA RAID 0/1/5/10.
  Ethernet
  1 x Realtek 1Gb Ethernet (Dedicated management LAN for AST2600)
  1 x Intel® dual 10Gb Ethernet
  ASUS LANGuard
  USB
  Rear USB (Total 9 ports)
  2 x USB 40Gbps (USB4®) with ASMedia ASM4242 controller ports (2 x USB Type-C®)
  6 x USB 10Gbps ports (6 x Type-A)
  1 x USB 2.0 ports (2 x Type-A )
  Front USB (Total 7 ports)
  1 x USB 20Gbpsconnector (supports USB Type-C®)
  1 x USB 5Gbps header supports 2 additional USB 5G ports
  2 x USB 2.0 headers support additional 4 USB 2.0 ports
  Audio
  Realtek ALC1220P Surround Sound High Definition Audio CODEC*
  – Impedance sense for front and rear headphone outputs
  – Internal audio Amplifier to enhance the highest quality sound for headphone and speakers
  – Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
  – High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)
  – Supports up to 32-Bit/192 kHz playback
  Audio Features
  – Premium audio capacitors
  – Dedicated audio PCB layers
  – Unique de-pop circuit

  *A chassis with an HD audio module in the front panel is required to support 5.1 Surround Sound audio output.
  * This motherboard will only support up to 5.1 Surround Sound due to the number of audio ports available on the motherboard.
  Back Panel I/O Ports
  2 x USB 40Gbps (USB4®) with ASMedia ASM4242 controller ports (2 x USB Type-C®)
  6 x USB 10Gbps ports (6 x Type-A)
  1 x USB 2.0 port (2 x Type-A)
  1 x VGA port
  2 x mini DisplayPort IN
  1 x Intel® dual 10Gb Ethernet ports
  1 x Realtek 1Gb Ethernet port
  2 x Audio jacks
  1 x BIOS FlashBack™  button
  1 x Clear CMOS button
  Internal I/O Connectors
  Fan and Cooling related
  1 x 4-pin CPU Fan header
  1 x 4-pin CPU OPT Fan header
  1 x W_PUMP+ header
  5 x 4-pin Chassis Fan headers
  2 x 4-pin VRM Fan header (with VRM FAN onboard)
  1 x 4-pin M.2 Fan header (with M.2 FAN onboard)
  Power related
  1 x 24-pin Main Power connectors
  2 x 8-pin +12V Power connectors
  2 x 8-pin PCIe to CPU power connectors
  2 x 8-pin PCIe Power connector
  Storage related
  4 x M.2 slots (Key M)
  4 x SATA 6Gb/s ports
  2 x SlimSAS port
  USB
  1 x USB 20Gbps connector supports USB Type-C®
  1 x USB 5Gbps header supports 2 additional USB 5Gbps ports
  2 x USB 2.0 headers support additional 4 USB 2.0 ports
  Miscellaneous
  1 x Chassis intrusion header
  1 x COM port header
  1 x FlexKey button
  1 x Front panel audio header (F_AUDIO)
  1 x LN2 mode jumper
  1 x M.2 slot (Key E)
  7 x ProbeIt measurement points
  1 x ReTry button
  1 x RSVD switch
  1 x Slow mode switch
  1 x Safe boot button
  1 x SPI TPM header (14-1 pin)
  1 x Start button
  1 x 10-1 pin system panel header
  1 x Thermal sensor header
  Special Features
  ASUS 5X PROTECTION III
  – DIGI+ VRM (- Digital power design with SPS)
  – ESD Guards
  – LANGuard
  – Overvoltage protection
  – SafeSlot
  – Stainless-steel back I/O
  ASUS Q-Design
  – M.2 Q-Latch
  – Q-Release Slim (with PCIe SafeSlot)
  – Q-Code
  – Q-Connector
  – Q-DIMM
  – Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])
  – Q-Slot
  ASUS Thermal Solution
  – M.2 heatsink backplate and onboard thermal pads
  – M.2 heatsink
  – Steel backplate
  – VRM heatsink design with active fans
  ASUS EZ DIY
  – BIOS FlashBack™ button
  – BIOS FlashBack™ LED
  – Clear CMOS button
  – ProCool II
  – Pre-mounted I/O shield
  – SafeSlot
  – SafeDIMM
  Bespoke Motherboard Design & Business Focused Features
  – 24/7 Reliability
  – Overcurrent Protection
  BMC Related
  1 x BMC switch
  1 x BMC LAN fixed IP switch
  1 x IPMI switch
  1 x Message LED header
  1 x microSD card socket
  2 x LAN LED headers
  1 x Location LED header
  1 x Location button header
  1 x PSU_SMB header
  1 x SMART_PSU switch
  1 x VGA switch
  1 x VGA header (Dedicated Management for AST2600)
  1 x VPP_I2C header
  Software Features
  ASUS Exclusive Software
  Armoury Crate
  – Fan Xpert 4
  ASUS CPU-Z
  Adobe Creative Cloud (Free Trial)
  Norton 360 for Deluxe (60 Days Free Trial)
  WinRAR (40 Days Free Trial)
  UEFI BIOS
  ASUS EZ DIY
  – ASUS CrashFree BIOS 3
  – ASUSTeK. EzFlash Utility
  FlexKey
  IT Management software supported
  – ASUS Control Center Express(ACCE)
  BIOS
  256 Mb Flash ROM, UEFI AMI BIOS(text-based)
  Manageability
  WOL by PME, PXE (UEFI mode)
  Accessories
  Cables
  2 x PCIe 8-pin to CPU power cables
  1 x 24-pin power cable (Y cable)
  2 x Mini DisplayPort cables
  4 x SATA 6Gb/s cables
  1 x Thermistor cable pack
  Miscellaneous
  1 x Q-connector
  1 x M.2 Q-Latch package
  1 x AMI license sticker
  4 x M.2 rubber packages
  1 x Screw package for M.2 Key E
  Documentation
  1 x ACC Express Activation Key Card
  1 x Quick start guide
  Operating System
  Windows® 11
  Windows® 10 64-bit
  Form Factor
  EEB Form Factor
  12 inch x 13 inch
  (30.5 cm x 33 cm)
